T2640 Stainless Steel Handle
RAYEN T2640 Stainless Steel Handle: centre distance 425mm (L450)/P=575mm (L600), overall length 450mm/600mm, grip section Ø25mm. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=425mm (L450) / P=575mm (L600) |
|---|---|
| Overall length | 450mm / 600mm |
| Grip section | Ø25mm |
| Projection | 60mm |
| Weight | 1.8kg |
| Available lengths | 450–600mm |
| Fixing screw | M8 |
| Fixing hole (glass door) | φ16mm |
| Fixing hole (timber door) | φ10mm |
