T3321 Stainless Steel Handle
RAYEN T3321 Stainless Steel Handle: centre distance 425mm, overall length 700mm, grip section 25mm. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
- Antique brass
Specification
| Centre distance | P=425mm |
|---|---|
| Overall length | 700mm |
| Grip length | 500mm |
| Grip section | 25mm |
| Projection | 52mm |
| Weight | 1kg |
| Fixing screw | M6 |
| Fixing hole | φ8mm |
| Fixing hole (glass door) | φ12mm |
