T5450 · 1 of 4
T5450 Stainless Steel Handle
RAYEN T5450 Stainless Steel Handle: centre distance 775mm, overall length 800mm, grip section 40mm. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=775mm |
|---|---|
| Overall length | 800mm |
| Grip section | 40mm |
| Grip length | 600mm |
| Projection | 78mm |
| Weight | 5.3kg |
| Fixing screw | M8 |
| Fixing hole (glass door) | φ16mm |
| Fixing hole (timber door) | φ10mm |
