G1111 Glass Door Handle
RAYEN G1111 Glass Door Handle: overall length 600mm/900mm/2000mm. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=425mm (L600) / P=700mm (L900) / P=700+500+700mm (L2000) |
|---|---|
| Overall length | 600mm / 900mm / 2000mm |
| Grip section | 22mm (L600) / Ø22mm (L900) / 30mm (L2000) |
| Stem diameter | 28mm |
| Projection | 64mm |
| Available lengths | 600–2000mm |
| Fixing screw | M6 |
| Fixing hole | φ12mm |
| Fixing hole (flush door) | φ8mm |
Matching range
This lever belongs to the same design family as the pull handles below.
