G1216 Glass Door Handle
RAYEN G1216 Glass Door Handle: centre distance 425mm, overall length 600mm, grip section Ø19mm, oval. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=425mm |
|---|---|
| Overall length | 600mm |
| Grip section | Ø19mm, oval |
| Projection | 60.6mm |
| Standoff | 25.6mm |
| Weight | 1.6kg |
| Fixing screw | M6 |
| Fixing hole | φ12mm |
| Fixing hole (flush door) | φ8mm |
Matching range
Matching lever handles in the same design: UL1042. Available as a set.
