G1266 Glass Door Handle
RAYEN G1266 Glass Door Handle: centre distance 540mm, overall length 600mm, grip section 40mm curved blade. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
- Antique brass
Specification
| Centre distance | P=540mm |
|---|---|
| Overall length | 600mm |
| Grip section | 40mm curved blade |
| Projection | 51mm |
| Standoff | Ø20mm |
| Weight | 1.7kg |
| Fixing screw | M6 |
| Fixing hole | φ12mm |
| Fixing hole (flush door) | φ8mm |
