G2110 Glass Door Handle
RAYEN G2110 Glass Door Handle: centre distance 660mm (L700)/P=260mm (L300), overall length 700mm/300mm, grip section 20mm square. Made in Xiaolan, Zhongshan, also to your drawing or sample.
Available finishes
- Satin stainless
- Matt black
Specification
| Centre distance | P=660mm (L700) / P=260mm (L300) |
|---|---|
| Overall length | 700mm / 300mm |
| Grip section | 20mm square |
| Projection | 68mm |
| Standoff | 20mm |
| Weight | 1kg |
| Available lengths | 300–700mm |
| Fixing screw | M6 |
| Fixing hole | φ12mm |
| Fixing hole (flush door) | φ8mm |
Matching range
This lever belongs to the same design family as the pull handles below.
